Type | Emitted color | Power | VF(V) 20mA | IV(mcd) 20mA | Wavelenght(nm) | Reverse current | Viewing Angle 2Ө 1/2 | |||
Min | Max | Min | Max | Min | Max | IF(µA) | ||||
S3528RBC | Red | 0.06W | 1.8 | 2.4 | 63 | 160 | 620 | 630 | ≤10 | 35±5° |
Blue | 0.06W | 2.8 | 3.7 | 80 | 200 | 465 | 475 | ≤10 | 35±5° | |
S3528RGC | Red | 0.06W | 1.8 | 2.4 | 100 | 320 | 620 | 630 | ≤10 | 35±5° |
Green | 0.06W | 2.8 | 3.7 | 320 | 800 | 565 | 575 | ≤10 | 35±5° | |
S3528BGC | Blue | 0.06W | 2.8 | 3.7 | 80 | 200 | 465 | 475 | ≤10 | 35±5° |
Green | 0.06W | 2.8 | 3.7 | 320 | 800 | 520 | 530 | ≤10 | 35±5° | |
S3528RYC | Red | 0.06W | 1.8 | 2.4 | 63 | 160 | 620 | 630 | ≤10 | 35±5° |
Yellow | 0.06W | 1.8 | 2.2 | 40 | 300 | 585 | 595 | ≤10 | 35±5° |
