型号:255mm插件方形无边
峰值参数:Absolute Maximum Rating(At TA=25°C)
Note:1. Derate linearly as shown in Figure 4 for temperature above 25°C.
产品参数:Absolute Maximum Rating(At TA=25°C)
<td width="61" style="padding: 1px 1px 0cm; line-height: 22px; background-image: initial; background-position: initial; background-size: ini
product name产品名称 | Part No. | Emitted Color | Power | λd (nm)/CCT(K) | 发光强度 | 顺向电压 | 反向电流 | Viewing Angle 2Ө 1/2 | Lens Type | |||
Iv(lm)ranks @IF=20mA | VF(V) | IF(µA) | ||||||||||
255白发红 | R255R302D | Red | 0.06W | 620 | 630 | 200 | 600 | 1.8 | 2.2 | ≤10 | 120±5° | Clear |
255白发橙 | R255O302D | Orange | 0.06W | 600 | 610 | 200 | 400 | 1.8 | 2.2 | ≤10 | 120±5° | Clear |
255白发黄 | R255Y302D | Yellow | 0.06W | 585 | 595 | 200 | 500 | 1.8 | 2.2 | ≤10 | 120±5° | Clear |
255白发绿 | R255G302D | Green | 0.06W | 510 | 530 | 1000 | 1900 | 3.2 | 3.6 | ≤10 | 120±5° | Clear |
255白发蓝 | R255B302D | Blue | 0.06W | 460 | 470 | 400 | 1100 | 3.2 | 3.6 | ≤10 | 120±5° | Clear |
255白发白 | R255W302D | Warm White | 0.06W | 2500 | 4000 | 800 | 2000 | 3.2 | 3.6 | ≤10 | 120±5° | Clear |
255白发白 | R255W302D | Positive white | 0.06W | 5000 | 8000 | 1000 | 2300 | 3.2 | 3.6 | ≤10 | 120±5° | Clear |
255白发白 | R255W302D | Cool white | 0.06W | 9000 | 20000 | 900 | 1500 | 3.2 |
